16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm

    Buy cheap 16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm from wholesalers

    Buy cheap 16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm from wholesalers
    • Buy cheap 16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm from wholesalers
    • Buy cheap 16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm from wholesalers

    16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm

    Ask Lasest Price
    Brand Name : Jingwang
    Model Number : CCG1000-16TJ
    Certification : CE,CO,ISO
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 1 Osets per month
    Delivery Time : 15-90 work days
    • Product Details
    • Company Profile

    16 Nozzles Pesticide Filling Machine Packing Machine 50-1000mL 60 Bpm

    60 Bpm Pesticide Filling Line Machine 50-1000mL16 Nozzles Packing Machine


    Overview of 60 BPM Pesticide Filling Machine Line


    The production line is designed and manufactured in accordance with the latest veterinary drug GMP standards and is suitable for the automated production of various 50-1000ml bottled oral liquids. Packaging process: automatic bottle unscramble, automatic filling, automatic capping, automatic check weighing, sealing, coding, aluminum foil sealing detection, automatic labeling, two-dimensional code collection and association, automatic box opening, automatic bottle loading into the boxes, and automatic carton sealing.

    It is widely used for the automatic filling from 80-1000ml in agrochemical, chemical, fertilizer, personal care products, oil and other related industries.

    60 Bpm Pesticide Filling Line Machine 0


    Main Technical Parameters of 60 BPM Pesticide Filling Machine Line


    1Filling Capacity1000mL:4000 bottles/hour *Filling water, (capacity is related to different products)
    2Applicable Bottle SizeRound bottle:Φ40-95mm H 80-250mm
    3Filling range, filling nozzles50-1000mL; 16 nozzles
    4Accuracy±1g(100mL) ±2g(1000mL)(*Filling water)
    5Height of Feeding Port2300mm
    6Feeding Port DiameterDn40
    7Nozzle DiameterΦ18mm
    8Minimum Bottle Opening≥Φ22mm
    9Air Pressure0.6-0.8MPa
    10Power Source~380V/60Hz/3.55KW
    11Dimension2835×1490×2480mm(L×W×H)
    12Weightaround1200Kg
    13Bottle Feeding DirectionFrom left to right

    About Us


    Our scientific approach towards designing and executing Agrochemical Facilities creates optimized and flexible manufacturing facilities that cater to all future requirements of our customers. We are a family of experts who have a common vision of providing the right solutions to our clients who produce quality pesticides, thereby improving millions of lives across the world.


    60 Bpm Pesticide Filling Line Machine 2


    Our Service


    1. Personalization
    2. Assistance
    3. Remote Support
    In light of the risks surrounding Covid-19, at Jinwang we have developed remote support procedures to keep our customers' orders and production progressing. We are completing machine FAT via video conference call and undertaking remote installations to get new machines up and running ASAP. Documents can be screened, and our teams can connect with your teams to provide the relevant training
